Find Galvanized Solar Led Street Light Pole, 9m Street Lighting Pole, Square Steel Galvanized Street Light Pole on Industry Directory, Reliable Manufacturer/Supplier/Factory from China.

Home > Products > Standard Ground Joint > Standard Height Galvanized Street Lighting

Standard Height Galvanized Street Lighting

  • Standard Height Galvanized Street Lighting
  • Standard Height Galvanized Street Lighting
  • Standard Height Galvanized Street Lighting
  • Standard Height Galvanized Street Lighting

Standard Height Galvanized Street Lighting

    Payment Type: L/C,T/T,Western Union
    Terms of Trade: FOB,CIF,EXW
    Min. Order: 1 Set/Sets
    Delivery Time: 7 Days
    Packaging: 1. Opp bag per piece; 2. 20 pieces in one normal export carton box; 3. Customized packing methods are available.
    Productivity: 5000
    Brand: BSW
    Transportation: Ocean,Land,Air
    Place of Origin: YANGZHOU
    Supply Ability: 100000
    Certificate: 3C CE
    Port: Shanghai,Ningbo

Basic Info

Model No.: BSW-108

Product Description

Light pole data sheet

Pole's height

3m to 15m

Shape of pole

Round conical, Octagonal tapered, Straight square; Tubular stepped; Shafts are made of steel sheet that folded into required shape and welded longitudinally by automaticarc welding machine

Brackets/ Arm

Single or double brackets/ arm are in the shape and dimension as per customers requirement

Length

Within 14m once forming without slip joint

Wall thickness

2.5mm to 20mm

Welding

It has past flaw testing.Internal and external double welding makes the welding beautiful in shape And confirms with international welding standard of CWB

Jointing

Jointing of pole with insert mode,innerflange mode,face to face joint mode.

Base plate mounted

Base plate is square or round in shape with slotted holes for anchor bolt and dimension as per customers requirement.

Ground mounted

The length buried underground as per customers requirement.

Galvanizing

Hot dip galvanization with thickness of 80-100um average in accordance with Chinese standard GB/T 13912- 2002 or American standard ASTM A123. IS: 2626-1985

Powder coating

Pure polyester powder painting, color is optional according to RAL Color stardand.

Wind Resistance

Aganist wind pressure of 160Km/h

Quality Control

We control the quality according to the flow of ISO9001-2008. Quality is employed at every stage of production to ensure the product compliance to the specifications/standards. Careful inspections are carried out by highly trained inspection engineers as per the defined procedures from raw material stage to finished.

Certificates

ISO9001-2008, SGS Audited Supplier

3C CE FCC RoHS…


Superiority Contrast

solar street light


Light pole

Light pole

Light pole


PRODUCT EXHIBITION

Light pole

Street lamp pole

Street lamp pole

Light pole


The First Plant

Street lamp pole


The Second Plant

99 (2)

Jiangsu Bosiwei Optoelectronics Group Co.,ltd



Jiangsu Bosiwei Optoelectronics Group Co., Ltd. has 4 subsidiaries, including three production institutions and one R&D institution. The annual output value of the group is hundreds of millions of yuan. It is a large-scale road transportation facility and road lighting manufacturer, committed to the field of smart transportation and intelligent lighting R&D, production and sales. The group has national-level qualifications for street lighting construction and transportation facilities.The products are selling well in domestic and overseas markets.
